LM-800UGP-I
As industrial networks expand, many businesses make a costly error: they use office-grade switches where they don’t belong. At first, everything works. Heat rises, dust settles, machines shake, and power fluctuates. Suddenly, the network is unstable. Cameras drop. Sensors disconnect. Production slows down.
In real industrial projects, downtime rarely starts because devices fail. It starts because the network hardware cannot survive the environment.
The LM-800UGP-I Industrial Unmanaged Switch is designed to solve this exact problem. It offers fast, reliable connections in factories, warehouses, outdoor CCTV locations, and energy sites. This happens without needing configuration, software, or fragile parts.
This is a switch built for reliability first, not features you don’t need.
Lanmus Ethernet Industrial Unmanaged (LM-800UGP-I)
8 Port 10/100/1000 Base-T
Model
LMT-GE-MM850
LMT-MM850
Series
LMT-GE-MM850
LMT-GE-MM850
LMT-GE-MM850
LMT-GE-MM850
Models
Gigabit
Gigabit
Hightlight Features
- Hardware Type: Industrial Unmanaged Ethernet Switch
- Port Configuration:8 × Gigabit Ethernet ports
- Switching Layer: Layer 2 (automatic forwarding)
- Management: None (true plug-and-play)
- Housing: Rugged industrial metal enclosure
- Mounting Options: DIN-rail / Wall mount
- Power Input: Industrial-grade power support
- Operating Environment: Harsh industrial conditions
- Operating Temperature: Designed for extreme heat and cold
- Usage Type: Indoor industrial/outdoor cabinet installations
Key Specifications
Product Information
| Product Category | Industrial Unmanaged PoE Switch |
| Warranty | 3 years |
Port Specifications
| Total number of optical ports | 0 (Uplink SFP mentioned in features but not listed in fixed ports) |
| Number of 1GE combo ports | 0 |
| Number of 1GE SFP ports | 0 |
| Number of 10GE SFP+ ports | 0 |
| Number of 10/100BASE-T ports | 0 |
| Number of 10/100/1000BASE-T ports | 8 |
| Number of 10/100/1000/2500BASE-T ports | 0 |
| Number of 100/1000/2.5G/5G/10GBASE-T ports | 0 |
Power Supply and Consumption
| Number of PoE Out ports | 8 |
| Number of PoE/PoE+ Out ports | 8 (Supports up to 30W per port) |
| Number of PoE/PoE+/PoE++ Out ports | 0 (Max 30W is PoE+ standard) |
| PoE budget | Not explicitly stated (30W max per port) |
| PoE power pins | 1,2(+) and 3,6(-) |
System Specifications
| Forwarding rate | 11.9 Mpps |
| Switching capacity | 16 Gbps |
Environment and Reliability
| MTBF | Not specified in datasheet |
| Operating temperature | -40°C to +75°C |
| Altitude | Not specified in datasheet |
| Surge protection | 4KV common-mode, 2KV differential mode |
Software Specifications
| PoE watchdog | Not specified |
| Jumbo frame length (MTU) | Not specified |
Security
| Port isolation | Not specified |
| Broadcast storm control | Not specified |
Understanding the LM-800UGP-I Industrial Switch
The LM-800UGP-I is an industrial unmanaged Ethernet switch. It’s built for tough environments with heat, dust, vibration, and power issues.
Unlike standard office switches, this model is engineered to:
Run 24/7 without interruption
Handle unstable power conditions
Operate in extreme temperatures
Survive vibration-heavy industrial sites
From real-world deployments in warehouses, factory floors, and outdoor CCTV cabinets, this switch is commonly chosen when:
Office switches fail due to heat or dust.
Networks must stay online without IT supervision.
Installers need fast deployment without configuration.
Reliability matters more than VLANs or monitoring tools.
It works as a core connectivity hub for industrial devices where simplicity and uptime are critical.
Key Features
The LM-800UGP-I uses a metal industrial enclosure that protects internal components from:
- Dust and debris
- Continuous vibration
- Temperature fluctuations
This makes it reliable in factories, transport systems, and outdoor network cabinets where office switches fail quickly.
True Plug-and-Play Operation
There is no configuration, no firmware, and no software dependency.
Connect your devices, power the switch, and it starts working instantly. This reduces installation time and removes the risk of misconfiguration—especially important for large-scale or time-sensitive projects.
Stable Gigabit Performance
Each of the 8 Ethernet ports supports Gigabit speed, allowing:
- Smooth CCTV video streams
- Reliable sensor data transmission
- Stable communication between controllers and systems
The switch automatically manages traffic flow, preventing common congestion issues.
Industrial-Grade Power Handling
Industrial sites often face:
- Voltage fluctuations
- Power noise
- Sudden restarts
The LM-800UGP-I is designed to stay stable in these conditions, reducing unexpected network outages.
Performance & Real-World Behavior
In practical use, the LM-800UGP-I performs best where network stability is more important than advanced control features.
Observed benefits from industrial projects include:
- Continuous CCTV uptime in dusty environments
- Stable device communication on production floors
- Reduced network-related service calls
- Longer hardware lifespan compared to office switches
Because it has no management layer, there are fewer failure points, making it dependable for long-term industrial use.
Applications & Use Cases
Factories & Production Lines
Connect PLCs, industrial controllers, sensors, and monitoring systems without worrying about vibration or heat.
Warehouses & Logistics Centers
Support barcode scanners, access points, and surveillance cameras in large storage facilities with minimal maintenance.
Outdoor CCTV & Smart City Projects
Ideal for CCTV poles and roadside cabinets when installed inside protective enclosures.
Transportation & Rail Systems
Maintain stable communication between cameras, signal controllers, and monitoring equipment.
Energy & Utility Plants
Connect control panels, meters, and environmental sensors where reliability is critical.
Installation & Maintenance Insights.
- Mount using DIN-rail or wall brackets in ventilated enclosures
- Use industrial-rated Ethernet cables for long cable runs
- Ensure proper grounding to protect against power surges
- Organize and label cables for easy troubleshooting
- Periodically check physical connections
Why Choose LM-800UGP-I?
- Designed specifically for industrial environments
- Stable 24/7 operation
- No configuration or technical expertise required
- Faster deployment for vendors and installers
- Lower long-term maintenance cost
- Ideal for UAE climate and global industrial use
- Backed by LANMUS product expertise and support
Order LM-800UGP-I from LANMUS
The LM-800UGP-I Industrial Unmanaged Switch is sold by LANMUS. It supports industrial projects in Dubai and the UAE. Plus, it can expand globally.
For pricing, technical consultation, or bulk orders:
[email protected]
https://lanmus.com/
Features
Product Comparision
24 *10/100/1000 PoE BaseT
4*100/1000Base-X
PoE ports
Max. PoE budget
Switching capacity
Forwarding rate
MAC address table
VLAN
Dimensions (W x D x H)
Weight (With package)
Loop prevention
Flow control
Port isolation
Broadcast storm suppression
Cloud management
Power consumption
Power supply
Fan
Port surge
Operating temperature
Operating humidity
MTBF
Warranty
LM-2404FMGP-L2
24
4
4
--
56Gbps
8K
--
440mm* 300mm*44mm
--
--
AC:100-240V50/60Hz)
--
-20~+55°C
5%~90% RH
--
3 years
LM-4804XFMGP-L3
48
4
4
--
176Gbps
32K
--
440mm* 300mm*44mm
--
--
AC100-240V 50/60Hz
--
-20~+55°C
5%~90% RH
--
3 years
Product Comparison
LM-500UGP-I
LM-800UGP-I
Interface Characteristics
Fixed Port
4 Port 10/100/1000 Base-T, 4GE+1GE Uplink Ports
8 Port 10/100/1000 Base-T
Ethernet Port
10/ 100/ 1000Base-TX auto-sensing, full/half duplex MDI/MDI-X self-adaption
10/ 100/ 1000Base-TX auto-sensing, full/half duplex MDI/MDI-X self-adaption
Twisted Pair Transmission
10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-T: Cat5e or later UTP(≤100 meter) 1000BASE-T ： Cat5e or later UTP(≤100 meter)
10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-T: Cat5e or later UTP(≤100 meter) 1000BASE-T ： Cat5e or later UTP(≤100 meter)
Chip Parameter
Network Protocol
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3u100Base-SX, IEEE802.3x IEEE802.3ab 1000Base-T；IEEE802.3z 1000Base-X；
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3u 100Base-SX, IEEE802.3x IEEE802.3ab 1000Base-T；IEEE802.3z 1000Base-X；
Forwarding Mode
Store and Forward(Full Wire Speed)
Store and Forward(Full Wire Speed)
Switching Capacity
10Gbps
16Gbps
Buffer Memory
7.44Mpps
11.9Mpps
MAC
8K
8K
PoE characteristics
power supply
DC : 52V
DC : 52V
PoE power supply method
Supports 1,2+, 3,6-power supply
Supports 1,2+, 3,6-power supply
PoE output power
Each port has a power supply of 15.4w and a maximum power of 30w per port
Each port has a power supply of 15.4w and a maximum power of 30w per port
Physical Parameter
Operation TEMP /Humidity
-40 +75 C;5%~90% RH Non condensing
-40~+75°C;5%~90% RH Non condensing
Storage TEMP /Humidity
-40 +85 C;5%~95% RH Non condensing
-40~+85°C;5%~95% RH Non condensing
Dimension (L*W*H)
116mm* 86.5mm*32.5mm
141mm* 100mm*41mm
Installation
Desktop, DIN rail
Desktop, DIN rail
Product Resources
- Download Product Datasheet
Order Informations
Device
LM-800UGP-I
Power Supply
DC : 52V
Quick Start Guide
1
Warranty Card
1
Dimension (w x d x h)
141mm* 100mm*41mm
Frequently Asked Question (FAQ)
Yes. It is built with rugged metal housing and industrial-grade components. It withstands vibration, dust, and temperatures from -40°C to 75°C. Unlike standard office switches, it keeps your network stable in factories, outdoor CCTV setups, and energy plants. This ensures uptime for important operations.
No. The LM-800UGP-I is plug-and-play. Simply connect your devices, power the switch, and it starts working. There is no need for VLAN configuration, routing setup, or command-line access. It's perfect for vendors, installers, and facilities managers. They can enjoy reliable connectivity without needing advanced technical skills.
No, this model does not include PoE. It focuses on providing stable, unmanaged connectivity. If you require PoE for IP cameras or access points, LANMUS industrial managed or PoE-enabled switches are recommended. The LM-800UGP-I is best for network stability and simplicity.
The switch offers 8 Gigabit ports, suitable for small to medium industrial setups. You can connect controllers, sensors, cameras, and computers. You can daisy-chain multiple LM-800UGP-I switches for larger networks. They can also work with other industrial LANMUS switches.
Yes, provided it is installed in a protective enclosure. Its metal housing resists heat, dust, and vibration. This makes it perfect for outdoor CCTV poles, transport monitoring systems, and smart city uses.
Office switches are designed for controlled indoor environments and may fail under heat, vibration, or dust. The LM-800UGP-I has industrial-grade parts. This means it’s reliable, lasts longer, and performs well in tough conditions. Office switches can’t promise the same.
Yes. The LM-800UGP-I uses standard Ethernet protocols, allowing seamless integration with LANMUS industrial managed switches or other network devices. You can mix unmanaged and managed switches depending on your project requirements.
Minimal maintenance is needed. Keep it in a ventilated space, check connections periodically, and ensure cables are organized. Firmware updates are not necessary as it is unmanaged, but regular inspection helps prevent downtime.
Yes. It provides stable connectivity for IP cameras, sensors, and monitoring devices. Good cabling and network planning ensure smooth video feeds and reliable device communication.
You can get it from LANMUS authorized distributors across Dubai and the UAE. For pricing, technical guidance, or project consultation, contact [email protected] or visit https://lanmus.com/. LANMUS also provides support for bulk orders, vendor deployments, and industrial project advice.
