LM-802UGP
10 ports PoE Ethernet Switch is a security surveillance Ethernet Switch which aims at Ethernet
high definition surveillance and security system.
Lanmus Ethernet Managed (LM-802UGP)
Standard Unmanaged 8GE+2GE 1000M POE Switch, 120w inbuilt Power Supply
8 downlink 10/100/1000Base-T PoE Ethernet ports, 2 uplink 10/100/1000Base-T Ethernet uplink ports
Series
LMT-GE-MM850
LMT-GE-MM850
LMT-GE-MM850
LMT-GE-MM850
Models
Gigabit
Gigabit
Hightlight Features
- Single port power supply 15.4w, maximum port power 30w, total machine power 120w
- Power Input:DC52V2.3A;
- Standard: IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab;
- Protection: Superior lightning protection(6KV), ESD protection and anti-interference ability;
- Structure: stable and delicate, easy to install;
Key Specifications
Downstream Ports
8*10/100/1000Base-T (PoE)
Uplink Ports
2*10/100/1000Base-T
Switching capacity
20Gbps
Switch Processing Scheme
Store and Forward
MAC
4K
Throughput
14.88Mpps
Network Standard
IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab
Power Supply
DC 52V2.3A
Dimensions (W x D x H)
195mm×130mm×40mm
Humidity(Noncondensin)
5%-95%
Storage temperature
-20℃~75℃
Work temperature
20℃~55℃
Features
Product Comparison
LM-402UGP
LM-802UGP
LM-1621FUGP
LM-2421FUGP
Downstream Ports
4*10/100/1000Base-T (PoE)
8*10/100/1000Base-T (PoE)
16*10/100/1000Base-T (PoE)
24*10/100/1000Base-T (PoE)
Uplink Ports
2*10/100/1000Base-T
2*10/100/1000Base-T
2*10/100/1000 Base-T RJ-45；1*1000 Base-X SFP
2*10/100/1000 Base-T RJ-45；1*1000 Base-X SFP
Network Standard
IEEE802.3, IEEE802.3u, IEEE802.3X, IEEE802.3ab
IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab
IEEE802.3, IEEE802.3u, IEEE802.3X, IEEE802.3ab
IEEE802.3, IEEE802.3u, IEEE802.3X, IEEE802.3ab
Switch Capacity
12Gbps
20Gbps
38Gbps
54Gbps
Throughput
8.93Mpps
14.88Mpps
28Mpps
40.176Mpps
Switch Processing Scheme
Store and Forward
Store and Forward
Store and Forward
Store and Forward
Memory Buffer
1M
1.5M
4M
4M
MAC Table
2K
4K
8K
8K
PoE Standard
802.3af/at(PSE)
802.3af/at(PSE)
802.3af/at(PSE)
802.3af/at(PSE)
PsE Type
End-span
End-span
End-span
End-span
Power Pin Assignment
1/2( +)，3/6(-)
1/2( +)，3/6(-)
1/2( +)，3/6(-)
1/2( +)，3/6(-)
PoE Power Output
Single port power 15.4w, maximum port power 30w
Single port power 15.4w, maximum port power 30w
Single port power 15.4w, maximum port power 30w
Single port power 15.4w, maximum port power 30w
PoE Total Power
65w
120w
260w
360W
Lightning protection
6KV Execute : IEC61000-4-5
6KV Execute : IEC61000-4-5
6KV Execute : IEC61000-4-5
6KV Execute : IEC61000-4-5
ESD
6KV Contact discharge 8KV Air discharge Execute：IEC61000-4-2
6KV Contact discharge 8KV Air discharge Execute：IEC61000-4-2
6KV Contact discharge 8KV Air discharge Execute：IEC61000-4-2
6KV Contact discharge 8KV Air discharge Execute：IEC61000-4-2
Power Supply
DC:52V1.25A
DC 52V2.3A
52V/3.8A
52V/5.76A
Power Dissipation
＜5w
＜5w
＜15w
＜20W
Work temperature
-20℃~55℃
-20℃~55℃
-20℃~55℃
-20℃~55℃
Storage temperature
-20℃~75℃
-20℃~75℃
-20℃~75℃
-20℃~75℃
Humidity(Noncondensin)
5%-95%
5%-95%
5%-95%
5%-95%
Dimension（ L ×W × H ）
195mm×130mm×40mm
195mm×130mm×40mm
310mm*210mm*44mm
310mm*210mm*44mm
Regulator
CE, FCC, ROHS
CE, FCC, ROHS
CE, FCC, ROHS
CE, FCC, ROHS
6-port 10/100/1000M PoE Ethernet switch
1 unit
1 unit
1 unit
1 unit
power line
1 article
1 article
1 article
1 article
User Guide
1 book
1 book
1 book
1 book
Warranty Card
1 Sheet
1 Sheet
1 Sheet
1 Sheet
Product Resources
- Download Product Datasheet
Order Informations
Device
LM-802UGP
Power Supply
DC 52V2.3A
Quick Start Guide
1
Warranty Card
1
Dimension (w x d x h)
195mm×130mm×40mm
Frequently Asked Question (FAQ)
An 8-port unmanaged PoE switch is a plug-and-play Ethernet switch that provides Power over Ethernet (PoE) to connected devices like IP cameras, wireless access points, and VoIP phones. It does not require configuration and is ideal for small businesses and home security networks. Popular models include: Standard unmanaged 8GE+2GE 1000M PoE switch
Lanmus 8-port gigabit PoE switch
The 8-port PoE switch power consumption depends on its PoE standard and total power budget:
✔ 802.3af (PoE) – Max 15.4W per port, 130W total
✔ 802.3at (PoE+) – Max 30W per port, 250W total
✔ 802.3bt (PoE++) – Max 60W+ per port, higher total For example, the Lanmus 8-port switch power consumption varies based on the devices connected.
An 8-port PoE switch typically delivers up to 30W per port for PoE+ devices. The total power budget depends on the model, but common specs include: 65W to 150W for entry-level PoE switches
Up to 250W for high-power PoE+ switches
Before purchasing, check the 8 * 10/100/1000Base-T PoE price and specs to ensure it meets your power requirements.
The best 8-port PoE switch for IP cameras should offer:
✔ Gigabit ports for smooth video streaming
✔ High PoE power budget for multiple cameras
✔ Long-range PoE support (250m mode) Top-rated options include: 8GE+2GE ports 250M long-range PoE switch
Standard unmanaged 8GE+2GE 1000M PoE switch
✔ Unmanaged PoE Switch – Best for simple plug-and-play installations with fixed IP cameras.
✔ Managed PoE Switch – Recommended for large-scale deployments, offering VLANs, traffic control, and advanced security. If you need basic home or office surveillance, an unmanaged Ethernet PoE switch 8GE + 2GE is sufficient.
✔ Gigabit Switch 8-Port 1000 Mbps – Supports 1Gbps speed for high-performance networking.
✔ Multi-port LAN switch – Can include multiple speed options (100M, 1G, or 10G) for different use cases. For fast data transfers and gaming, go with a gigabit switch 8-port 1000 Mbps.
